Parsing the XMLRPC webservice response in Android

Parsing the XMLRPC webservice response in Android

For the last few days I have been intensively playing with Android and Magento XMLRPC API. One of the trickiest things for me as a PHP developer was to figure out how to parse the data returned from XMLRPC API. Most of the time you will most likely have a proper documentation that will clearly outline the result data format. However, its nice to grasp some basic logic and learn a thing or two.

After bashing my head with several “hard” to parse result data from Magento API I decided to play a bit with figuring out the response format like there was not documentation. Below is a result of simple but practical way of figuring the returned result format.

//(-1) Start Simple, as general object type
//Object customerGroupList = null;
//(0) Result of (1) after doing things based on (0)
Object[] customerGroupList = null;
try {
//(-1) Doing the web service call like (-1) data type
//customerGroupList = client.callEx("call", new Object[] { session, "customer_group.list"});
//(0) Doing the web service call like (0)
customerGroupList = (Object[])client.callEx("call", new Object[] { session, "customer_group.list"});
} catch (Exception e) {
Log.d("APP_INFO", "Exception: " + e.getMessage());
//(1) Check if the response isArray
//Log.i("APP_INFO", String.valueOf(customerGroupList.getClass().isArray()));
* 06-14 17:34:40.141: INFO/APP_INFO(489): true
//(2) If isArray, then iterate over it
for(Object o : customerGroupList) {
//(3) Get the type of object in the loop
Log.i("APP_INFO", o.getClass().getName());
* 06-14 17:39:17.231: INFO/APP_INFO(515): java.util.HashMap
//(4) Cast to appropriate object based on (3)
HashMap map = (HashMap)o;
//(5) Find out the fields/keys available in HashMap
Log.i("APP_INFO", "keys: " + map.keySet().toString());
* 06-14 17:42:50.051: INFO/APP_INFO(541): keys: [customer_group_id, customer_group_code]
//(6) Finally, play with the data :)
Log.i("APP_INFO", "Your data values are: 'customer_group_id'=> " + map.get("customer_group_id") + ", 'customer_group_code'=> " + map.get("customer_group_code"));
* 06-14 17:46:14.231: INFO/APP_INFO(567): Your data values are: 'customer_group_id'=> 3, 'customer_group_code'=> Retailer

In the above example I have been using the open source Android-XMLRPC library to connect to Magento API.

Please keep in mind that above example is not copy-paste ready, it is extracted from other larger portion of my code. My intention was just to demonstrate how to work your way trough possible data parse glitches.

Unlike all forgiving PHP, Java is quite strict and it forces you to do proper and on time data type casting. Which is not an issue once you get the hang of it.

Hope that the above example gives you few ideas.
